Agile and Compact Design for Urban Sites : Designed with a shorter wheelbase and optimal turning radius, this light duty concrete mixer easily navigates through narrow city alleys, tight residential areas, and height-restricted construction projects.
High-Wear-Resistant Manganese Steel Drum : The mixing drum features high-tensile alloy steel with customized internal blades, ensuring incredible structural durability against concrete friction and guarantees uniform mixing without segregation.
Top-Tier Integrated Hydraulic System : Equipped with high-precision imported or premium domestic hydraulic pumps and motors, delivering consistent drum rotation speeds during heavy-duty transit and smooth discharge.
Outstanding Fuel Economy & Low Upkeep : Powered by an advanced, emission-compliant light diesel engine that offers high torque at low speeds, significantly lowering fleet operational costs and daily fuel consumption.
Exceptional Value & High Commercial ROI : Combines Foton’s reliable manufacturing tech with an affordable factory direct price, minimizing your initial procurement risk and securing a faster asset payback period.
Custom trailer available, contact us to get lowest factory cost!
Get a Free Quote Now
| Parameter | English Technical Specifications |
|---|
| Product Model | FT-5CBM Light Duty Transit Mixer Truck |
| Drive Type | 4x2 Drive, Left Hand Drive (RHD Optional) |
| Wheelbase | 3360 mm / 3600 mm |
| Mixing Volume | Geometric Volume: 8.5 m³; Agitating Volume: 5 m³ |
| Engine Model | Cummins F3.8NS6B156 / Yuchai YCY24 (Turbocharged) |
| Max Power | 156 HP (115 kW) @ 2600 rpm |
| Max Torque | 500 N·m @ 1200-1900 rpm |
| Emission Standard | Euro 3 / Euro 4 / Euro 5 / Euro 6 Compliant |
| Transmission | FAST 6DS50T, 6 Forward + 1 Reverse |
| Chassis Axles | 3.5T Front Axle / 8T Reinforced Rear Axle (Ratio: 4.875) |
| Drum Material | 5mm High-Tensile Wear-Resistant Alloy Steel (Q345B) |
| Drum Blades | 4mm alloy steel with anti-wear protection strips |
| Drum Speed | Charging: ≥3 m³/min; Discharging: ≥2 m³/min |
| Discharge Residual | Ultra-low residual rate < 0.45% |
| Hydraulic Pump | Eaton/ Rexroth Heavy Duty |
| Hydraulic Motor | Eaton / Interpump High Pressure Motor |
| Speed Reducer | PMP/ TOP/ ZF Brand |
| Water Supply System | 300L - 400L Air Pressure Water Tank with hose |
| Tire Configuration | 8.25R20 / 9.00R20 All Steel Radial Tires (6+1 pcs) |
| Braking System | Dual-circuit air brake, exhaust brake, equipped with ABS |
1. Urban Narrow Streets & Alley Construction : The ideal transit mixer truck for municipal maintenance, sidewalk repairs, and historical neighborhood renovations where large 10-wheeler mixer trucks simply cannot enter.
2. Rural Infrastructure & Township Road Building : Perfectly fits township bridge constructions and rural narrow road paving, operating safely on softer roads and tight country pathways due to its lighter vehicle specifications.
3. Small-Scale Real Estate & Private Housing : Provides highly cost-effective and flexible ready-mix transport for small private building foundations, villa courtyard concrete casting, and localized industrial park factory floor pouring.
Transportation methods: Roll-on/roll-off, bulk cargo, and container shipping. We can provide the most economical trucking solutions for these three modes based on customer needs.
Ready to enhance your transport efficiency?
Get a Free Quote Now
We welcome customers from around the world to visit our factory and inspect our vehicles in person. These face-to-face exchanges allow our partners to directly verify our production capabilities, quality standards, and customized solutions, while building long-term, mutually trusting partnerships based on transparent and reliable communication.
1.Does your company has your own factory?
Yes,we have a factory ourself,our factory is very famous in shan dong,china.
2.Do you support customization?
Definitely!We can make the trucks based on your requirement.
3.What's your minimum quantity?
1 set.
4.How to trust us?
We provide customers with high-quality products and adhere to integrity. Welcome to visit our company or communicate through video call.
5.What's your payment term?
We accpet both T/T and L/C T/T:30% deposit by T/T,70% balance should be paid before shipment.
6.How about the delivery time? How do you transport the semi trailers ?
A: Within 15-35 days after we confirm you requirement. We transport the vehicle by bulk or container. Our factory possess long -term cooperation with ship agency which can provide you lowest shipping fee.
